Linear Profile
LED Linear Profile
Linear profile luminaire that can be surface-mounted or suspended. This energy-efficient and high-performance fitting also benefits from being able to adjust the height to suit your lighting requirements.
220-240V / 50/60Hz
30,000hrs / 50,000hrs
3/5
IP40
Product Overview
Surface Mounted
Directional Lighting
Seamless Integration
Housing Extruded Aluminum
Diffuser Opal PC diffuser
Clipping Stainless steel screws
Reflector Galvanized metal sheet
Dimension LXXX * W50*H75 mm
LED Light Source MST / osram / Philips
Diver Philips / osram / Vossloh-Schwabe
Industry
Educational institutions
Lobbies and restaurants
Offices
| Driver | Length | Power | Luminaire Luminous | Efficiency | Color Temperature | Power Factor | Beam Angle |
|---|---|---|---|---|---|---|---|
| Philips | 580mm | 20W | 1800Lm | 90Lm/w | 3000-4000-6500K | 0.97 | 120° |
| Philips | 860mm | 30W | 2700Lm | 90Lm/w | 3000-4000-6500K | 0.97 | 120° |
| Philips | 1140mm | 40w | 3600Lm | 90Lm/w | 3000-4000-6500K | 0.97 | 120° |
| Philips | 1420mm | 50w | 4500Lm | 90Lm/w | 3000-4000-6500K | 0.97 | 120° |
| Vossloh- Schwabe/ Osram | 860mm | 34w | 3060Lm | 90Lm/w | 3000-4000-6500K | 0.97 | 120° |
| Vossloh- Schwabe/ Osram | 1140mm | 46w | 4140Lm | 90Lm/w | 3000-4000-6500K | 0.97 | 120° |
| Vossloh- Schwabe/ Osram | 1420mm | 57w | 5130Lm | 90Lm/w | 3000-4000-6500K | 0.97 | 120° |
Ideal For
Industry
Educational institutions
Lobbies and restaurants
Offices
